The poultry cage conveyor is transmission machinery for transporting poultry cages. It enables poultry cages to move at a constant speed under the duck hanging assembly line, facilitating poultry hanging, and transporting empty poultry cages to designated positions with adjustable conveying speed. The equipment consists of frame, power system, transmission system and conveyor belt.
Watch belt type poultry cage conveyor working on slaughter line.
Manual handling of poultry cages is labor-intensive, with inconsistent transport speed and disordered empty cage recycling, which affects the continuity of poultry hanging operation on slaughter line.
Our belt type poultry cage conveyor cooperates with overhead hanging slaughter line. It delivers poultry cages stably at uniform speed for poultry hanging work, and automatically transports empty cages to target area. Speed can be adjusted to match your whole slaughter line capacity.
Driven by power and chain transmission system, the PVC conveyor belt runs at a constant speed. Poultry cages are placed on the belt and move along with the belt under the hanging line. Workers can complete poultry hanging operation conveniently. After unloading poultry, empty cages are conveyed to the specified position automatically. The conveying speed can be adjusted according to production requirements.
Stainless Steel Frame: Made of 40*3.0 stainless steel square tube, size 12000*780*700, sturdy and anti-corrosion, easy to clean.
Power System: Yongjia MB15D reducer, speed ratio 15-75 manually adjustable, motor power 1.5KW.
Chain Transmission: Low power loss, stable and reliable transmission.
Conveyor Belt: PVC cord-reinforced high-strength non-toxic environmental belt, belt width 600mm, thickness 6mm.
Stable continuous conveying for poultry slaughterhouse
Reducer speed ratio 15-75 manual adjustment, match different line production capacity.
40*3.0 stainless steel square tube frame, corrosion resistant, easy washdown for slaughter workshop.
PVC夹线 reinforced belt, non-toxic and eco-friendly, high tensile strength, long service life.
Chain transmission design, stable running, less energy consumption, low failure rate.
Basic parameters for slaughter line layout design
| Item | Parameter |
|---|---|
| Product Name | Belt Type Poultry Cage Conveyor |
| Overall Dimension | 12000*780*700mm |
| Frame Material | 40*3.0 Stainless Steel Square Tube |
| Reducer Model | Yongjia MB15D |
| Speed Ratio | 15-75, manually adjustable |
| Motor Power | 1.5KW |
| Transmission Mode | Chain transmission, low power loss |
| Conveyor Belt | PVC cord-reinforced high strength non-toxic eco belt, width 600mm, thickness 6mm |
| Application | Match hanging duck/poultry slaughter line, transport poultry cages and recycle empty cages |
Reminder: Custom size available according to customer workshop layout and line requirement.
Poultry cage feeding → Belt Type Poultry Cage Conveyor → Poultry hanging on shackle line → Stunning → Bloodletting → Scalding → Plucking → Evisceration → Pre-chilling
Empty poultry cages are recycled and conveyed back to designated position by this conveyor automatically.
Support duck, chicken and goose slaughterhouse production line
Each belt type poultry cage conveyor is manufactured in Haoze factory. Before shipment, we test running status, speed adjustment, chain transmission and belt stability. All stainless steel parts are checked carefully. Running test videos and photos can be provided for customer confirmation.
Steel frame + fumigated wooden case for spare parts, moisture-proof for ocean shipping.
EXW, FOB, CIF, DDP available.
15‑30 working days after order confirmation.
Layout suggestion, on-site installation guidance and operator training.
